2H0/2HZ
2-3-6
YC4 1 RLSOLN O 0/24 V DC FSSOL (return): On/Off
Connected
to the
optional
built-in fin-
isher and
optional job
separator
2 SLSOLN O 0/24 V DC FSSOL (activate): On/Off
3 SCLK O 0/5 V DC (pulse) Built-in finisher/Job separator clock signal
4 LOPSDI I 0/5 V DC (pulse) Built-in finisher serial communication data signal/
Job separator JBESW: On/Off
5 LOPSDO O 0/5 V DC (pulse) Built-in finisher/Job separator serial communica-
tion data signal
6 LOPRDY I 0/5 V DC Built-in finisher ready signal/Job separator
EPDSW: On/Off
7 LOPSEL O 0/5 V DC Built-in finisher/Job separator select signal
8 GND - - Ground
9 +5VSL O 5 V DC 5 V DC power output to built-in finisher/Job sepa-
rator
10 GND - - Ground
11 GND - - Ground
12 +24VSL O 24 V DC 24 V DC power output to built-in finisher/Job sep-
arator
13 +24VSL O 24 V DC 24 V DC power output to built-in finisher/Job sep-
arator
YC5 1 DET I 0/5 V DC Document finisher connection signal
Connected
to the
optional
document
finisher
2 DFSDO O 0/5 V DC (pulse) Document finisher serial communication data
signal
3 DFSDI I 0/5 V DC (pulse) Document finisher serial communication data
signal
4 DFSCLK O 0/5 V DC (pulse) Document finisher clock signal
5 DFSEL O 0/5 V DC Document finisher select signal
6 SISEL - - Not used
7 DFRDY I 0/5 V DC Document finisher ready signal
8 SIRDY - - Not used
YC7 1 MPFSIZE0 I 0/5 V DC MPPWSW: On/Off
Connected
to the MP
tray unit
2 MPFSIZE1 I 0/5 V DC MPPWSW: On/Off
3 MPFSIZE2 I 0/5 V DC MPPWSW: On/Off
4 GND - - Ground
5 +5VSL O 5 V DC 5 V DC power output to MPPSW
6 MPFPAPS I 0/5 V DC MPPSW: On/Off
7 GND - - Ground
8 +24VSL O 24 V DC 24 V DC power output to MPPFCL
9 MPFPAPCL O 0/24 V DC MPPFCL: On/Off
10 +24VSL O 24 V DC 24 V DC power output to MPFCL
11 MPFFECL O 0/24 V DC MPFCL: On/Off
12 +5VSL O 5 V DC 5 V DC power output to MPPLSW
13 MPFLENGTH I 0/5 V DC MPPLSW: On/Off
14 GND - - Ground
Connector Pin No. Signal I/O Voltage Description
