Kyocera KM-2560

2H0/2HZ
2-3-8
YC10 1 +24VSL O 24 V DC 24 V DC power output to MM
Connected
to the main
motor, drum
motor, paper
feed motor
and drum
heater
2 +24VSL O 24 V DC 24 V DC power output to DM
3 +24VSL O 24 V DC 24 V DC power output to MM
4 +24VSL O 24 V DC 24 V DC power output to DM
5 GND - - Ground
6 GND - - Ground
7 GND - - Ground
8 GND - - Ground
9 MMOTLOCK I 0/5 V DC MM lock signal
10 DMOTLOCK I 0/5 V DC DM lock signal
11 MMOTON O 0/24 V DC MM: On/Off
12 DMOTON O 0/24 V DC DM: On/Off
13 MMOTCCW O 0/5 V DC MM rotation switch signal
14 DMOTCCW O 0/5 V DC DM rotation switch signal
15 MMOTCLK O 0/5 V DC (pulse) MM clock signal
16 DMOTCLK O 0/5 V DC (pulse) DM clock signal
17 +24VSL O 24 V DC 24 V DC power output to PFM
18 +24VSL O 24 V DC 24 V DC power output to PFM
19 GND - - Ground
20 GND - - Ground
21 SMOTLOCK I 0/5 V DC PFM lock signal
22 SMOTON O 0/24 V DC PFM: On/Off
23 SMOTCCW O 0/5 V DC PFM rotation switch signal
24 SMOTCLK O 0/5 V DC (pulse) PFM clock signal
25 +24VSL O 24 V DC 24 V DC power output to DH
26 DHEATREM O 0/24 V DC DH: On/Off
YC11 1 +24V1 O 24 V DC 24 V DC power output to FSSOL
Connected
to the feed-
shift sole-
noid
2 DFSOLDR O 0/24 V DC FSSOL (activate): On/Off
3 DFSOLRS O 0/24 V DC FSSOL (return): On/Off
YC12 1 +24VIL2 O 24 V DC 24 V DC power output to HVTPWB
Connected
to the high
voltage
PWB
2 DHVSRUP O 0/5 V DC Developing slowup signal
3 DHVCLKC O 0/5 V DC (pulse) Developing bias clock signal
4 SHVDRN O 0/5 V DC Separation high voltage: On/Off
5 MHVDRN O 0/5 V DC Main charging high voltage: On/Off
6 GND - - Ground
7 GND - - Ground
8 DHVADJC O Analog Developing bias adjust signal
9 SHVISELN O 0/5 V DC Separation high voltage switch signal
10 THVADJC O Analog Transfer high voltage adjust signal
11 THVDRN O 0/5 V DC Transfer high voltage: On/Off
12 +5V O 5 V DC 5 V DC power output to HVTPWB
Connector Pin No. Signal I/O Voltage Description
