Kyocera KM-2560

2H0/2HZ
2-3-14
Connector Pin No. Signal I/O Voltage Description
YC13 1 FPSTAT O 0/3.3 V DC Operation panel status signal
Connected
to the main
operation
unit PWB
2 LED_PANEL1 O 0/3.3 V DC (pulse) Operation panel Indicator LED drive signal 1
3 LED_PANEL0 O 0/3.3 V DC (pulse) Operation panel Indicator LED drive signal 0
4 RST_PANELN O 0/3.3 V DC OPWB-M reset signal
5 HLDPANEL O 0/3.3 V DC Operation panel displaying enable signal
6 SW_FOOTN - - Not used
7 24V_DOWN O 0/3.3 V DC 24 V DC power shut-off signal
8 SPEND_ENTR O 0/3.3 V DC Energy save mode control signal
9 AUDIO_KUIO O Analog Audio output signal
10 SGND - - Ground
11 PH_KEY I 0/5 V DC Power key: On/Off
12 SGND - - Ground
13
+5V O 5 V DC 5 V DC power output to OPWB-M
YC14 1 VBUS O 5 V DC 5 V DC power output
Connected
to the main
operation
unit PWB
2 DATA- I/O - USB data signal
3 DATA+ I/O - USB data signal
4 N.C. - - Not used
5 GND - - Ground
YC17 1 VBUS O 5 V DC 5 V DC power output
Connected
to the USB
slot
2 DATA- I/O - USB data signal
3 DATA+ I/O - USB data signal
4 N.C. - - Not used
5 GND - - Ground
YC18 1 5V O 5 V DC 5 V DC power output to CCDPWB
Connected
to the CCD
PWB
2 5V O 5 V DC 5 V DC power output to CCDPWB
3 5V O 5 V DC 5 V DC power output to CCDPWB
4 CCDB I Analog CCD output signal
5 CCDBN - - Ground
6 CCDG I Analog CCD output signal
7 CCDGN - - Ground
8 CCDR I Analog CCD output signal
9 CCDRN - - Ground
10 GND - - Ground
11 GND - - Ground
12 SHBW O 0/3.3 V DC B/W shift signal
13 GND - - Ground
14 SHRGW O 0/3.3 V DC Color shift signal
15 GND - - Ground
16 SW O 0/3.3 V DC Color/B/W switch signal
17 GND - - Ground
18 RSN O 0/3.3 V DC CCD control signal
19 GND - - Ground
20 CCDCLKN O 0/3.3 V DC (pulse) CCD clock signal
