Kyocera KM-2560

2H0/2HZ
2-3-16
YC22 1 +5V I 5 V DC 5 V DC power input from PSPWB
Connected
to the power
source PWB
2 +5V I 5 V DC 5 V DC power input from PSPWB
3 +5VSL I 5 V DC 5 V DC power input from PSPWB
4 +12VSL I 12 V DC 12 V DC power input from PSPWB
5 +24VSL I 24 V DC 24 V DC power input from PSPWB
6 GND - - Ground
7 GND - - Ground
8 GND - - Ground
9 GND - - Ground
10 GND - - Ground
YC23 1 +12VSL O 12 V DC 12 V DC power output to HDD
Connected
to the hard
disk
2 GND - - Ground
3 GND - - Ground
4 +5VSL O 5 V DC 5 V DC power output to HDD
YC24 1 +12VSL O 12 V DC 12 V DC power output to OPWB-M
Connected
to the main
operation
unit PWB
2 +5V O 5 V DC 5 V DC power output to OPWB-M
3 +5V O 5 V DC 5 V DC power output to OPWB-M
4PGND -- Ground
5SGND -- Ground
6SGND -- Ground
7 N.C. - - Not used
YC26 1 +5V O 5 V DC 5 V DC power output to CFM6
Connected
to the cool-
ing fan
motor 6
2 CTL_FAN O 0/5 V DC CFM6: On/Off
YC27 1 GND - - Ground
Connected
to the power
source PWB
2 +5VSL I 5 V DC 5 V DC power input from PSPWB
Connector Pin No. Signal I/O Voltage Description
