Kyocera KM-2560

2H0/2HZ
2-3-18
Connector Pin No. Signal I/O Voltage Description
YC1 1 VBUS I 5 V DC 5 V DC power input
Connected
to the main
PWB
2 DATA- I/O - USB data signal
3 DATA+ I/O - USB data signal
4 N.C. - - N.C.
5 GND - - Ground
YC2 1
+5V I 5 V DC 5 V DC power input from MPWB
Connected
to the main
PWB
2SGND -- Ground
3 PH_KEY O 0/5 V DC Power key: On/Off
4SGND -- Ground
5 AUDIO_KUIO I Analog Audio output signal
6 SPEND_ENTR I 0/3.3 V DC Energy save mode control signal
7 24V_DOWN I 0/3.3 V DC 24 V DC power shut-off signal
8 SW_FOOTN - - Not used
9 HLDPANEL I 0/3.3 V DC Operation panel displaying enable signal
10 RST_PANELN I 0/3.3 V DC OPWB-M reset signal
11 LED_PANEL0 I 0/3.3 V DC (pulse) Operation panel Indicator LED drive signal 0
12 LED_PANEL1 I 0/3.3 V DC (pulse) Operation panel Indicator LED drive signal 1
13 FPSTAT I 0/3.3 V DC Operation panel status signal
YC3 1 KEY0 I 0/3.3 V DC (pulse) Operation panel key scan return signal 0
Connected
to the right
operation
unit PWB
2 KEY1 I 0/3.3 V DC (pulse) Operation panel key scan return signal 1
3 KEY2 I 0/3.3 V DC (pulse) Operation panel key scan return signal 2
4 KEY3 I 0/3.3 V DC (pulse) Operation panel key scan return signal 3
5 KEY4 I 0/3.3 V DC (pulse) Operation panel key scan return signal 4
6 SCAN0 O 0/3.3 V DC (pulse) Scan signal 0
7 SCAN1 O 0/3.3 V DC (pulse) Scan signal 1
8 SCAN2 O 0/3.3 V DC (pulse) Scan signal 2
9 SCAN3 O 0/3.3 V DC (pulse) Scan signal 3
10 SCAN6 O 0/3.3 V DC (pulse) Scan signal 6
11 LED0 O 0/3.3 V DC (pulse) Operation panel Indicator LED drive signal 0
12 LED1 O 0/3.3 V DC (pulse) Operation panel Indicator LED drive signal 1
13 Wake Up I 0/5 V DC Power key: On/Off
14 5V_MSWON O 5 V DC 5 V DC power output to OPWB-R
15 SGND - - Ground
YC4 1 KEY5 I 0/3.3 V DC (pulse) Operation panel key scan return signal 5
Connected
to the left
operation
unit PWB
2 KEY6 I 0/3.3 V DC (pulse) Operation panel key scan return signal 6
3 KEY7 I 0/3.3 V DC (pulse) Operation panel key scan return signal 7
4 SCAN0 O 0/3.3 V DC (pulse) Scan signal 0
5 SCAN1 O 0/3.3 V DC (pulse) Scan signal 1
6 SCAN2 O 0/3.3 V DC (pulse) Scan signal 2
7 SCAN3 O 0/3.3 V DC (pulse) Scan signal 3
8 LED2 O 0/3.3 V DC (pulse) Operation panel Indicator LED drive signal 2
9 LED3 O 0/3.3 V DC (pulse) Operation panel Indicator LED drive signal 3
10 LED4 O 0/3.3 V DC (pulse) Operation panel Indicator LED drive signal 4
11 SGND - - Ground
