Overview of PRESCRIBE Commands by Function
7
Raster Graphics Commands
Raster graphics commands can be used to draw any graphic design by specifying the
individual dots. The dot resolution is selectable from 75, 100, 150, 200, 300, 600, and
1200 dots per inch.
Color Commands
Color commands are used to create a color palette, assign colors to a palette, and specify
colors. In this manual, color commands are marked with under the command
name.
FILL FILL closed path 101
FLAT set FLATness 104
NEWP start NEW Path 176
PARC in Path, draw ARC 182
PCRP iin Path, Curve to Relative Position 186
PCZP in Path, Curve to Zero-relative Position 188
PDIR set Print DIRection 190
PDRP in Path, Draw to Relative Position 193
PDZP in Path, Draw to Zero-relative Position 195
PELP in Path, draw ELlipse 197
PMRA in Path, Move to Relative po
sition
specified by Angle 201
PMRP in Path, Move to Relative Position 203
PMZP in Path, Move to Zero-relative Position 205
PRBX in Path, draw Round BoX 209
PRRC in Path, at Relative position, draw
aRC 21
1
RPG Return to Previous Graphics state 228
SCAP Set line CAP 266
SCG Save Current Graphics state 272
SDP Store Dash Pattern 285
SIMG Set IMaGe model 298
SLJN Set Line JoiN 305
SMLT Set Miter LimiT 313
STRK STRoKe current path 344
Command Function Page
ENDR END Raster data 96
PXPL PiXel PLacement 214
RVCD ReceiVe Compressed raster Data 238
RVRD ReceiVe Raster Data 240
SRO Set Raster Options 330
SROP Set Raster OPeration 332
STR SeT dot Resolution 343
Command Function Page
