2NC/2NF/2NG/2NN/3P7/3P8/3P9
1-5-22
5. Release three wire saddles.
6. Remove the connectors(YC1 and YC7 )
from the engine PWB.
Figure 1-5-35
7. Release three wire saddles.
8. Remove the connectors(YC2006 and
YC2011 ) from the engine PWB.
Figure 1-5-36
Main/Engin PWB
Connector
(YC1)
Wire saddle
Wire saddles
Connecto
(YC7)
Main/Engine PWB
Connector
(YC2006)
Connector
(YC2011)
FFC
Aperture
To Next Page
