Kyocera TASKalfa 2201 - Detaching and Refitting the Drum Unit

2NC/2NF/2NG/2NN/3P7/3P8/3P9
1-5-40
(1) Detaching and refitting the drum unit
Procedure
1. Pull the developer evacuation lever for-
ward.
Figure 1-5-68
2. Open the right cover.
Figure 1-5-69
Front cover
Developer evacuation lever
Right cover
