Kyocera TASKalfa 2201 - Detaching and Refitting the Left Tray and Right Tray

2NC/2NF/2NG/2NN/3P7/3P8/3P9
1-5-78
(8) Detaching and refitting the left tray and right tray
Procedure
1. Remove the left tray.
Figure 1-5-138
2. Remove the screw.
3. Remove the right tray.
Figure 1-5-139
Left tray
Screw
Right tray
