Kyocera TASKalfa 2201 - Image Is out of Focus

2NC/2NF/2NG/2NN/3P7/3P8/3P9
1-4-59
(13) Image is out of focus.
1. Table scanning
2. DP-scanning
Print example
Defective part Check description Corrective Action
1
Original document Check whether the original
document is wavy.
If the original document is wavy, straighten.Or,
replace the original document.
2
Contact glass Check whether the contact glass
is dew condensed.
If the contact glass is dew condensed, remove
the dew.
3
Lens Check whether the lens is dew
condensed.
If the lens is dew condensed, remove the dew.
4
CIS Check whether the CIS glass is
dew condensed.
If the CIS glass is dew condensed, remove the
dew.
5
Adjustment of the
scanner
Check the automatic adjustment
of the scanner.
Perform maintenance mode U411,
table(Chart1)_All.
(see page 1-3-75)
6
CIS The CIS is defective. Replace the CIS and perform U411.
(see page 1-3-75)
7
Main/Engine PWB The main/engine PWB is defec-
tive.
Replace the main/engine PWB.(see page 2-2-
11)
Defective part Check description Corrective Action
1
Original document Check whether the original
document is wavy.
If the original document is wavy, straighten.Or,
replace the original document.
2
Contact glass Check whether the contact glass
is dew condensed.
If the contact glass is dew condensed, remove
the dew.
3
Lens Check whether the lens is dew
condensed.
If the lens is dew condensed, remove the dew.
4
CIS Check whether the CIS glass is
dew condensed.
If the CIS glass is dew condensed, remove the
dew.
