Kyocera TASKalfa 2201 - Page 327

2NC/2NF/2NG/2NN/3P7/3P8/3P9-1
1-5-49
4. Remove two screws.
5. Remove the fuser unit by pulling for-
ward.
Figure 1-5-82
*: Pull out with the part of the account of the
right for high temperature.
Figure 1-5-83
Screw
Screw
Fuser unit
Operation part
