Kyocera TASKalfa 2201 - Page 400

2NC/2NF/2NG/2NN/3P7/3P8/3P9-2
2-2-10
YC2010
7VDOP
O LVDS Video data signal(+)
Connected to
APC PWB
8LDEN
O 0/3.3 V DC Laser output permission signal
YC2011
1GND
- - Ground
Connected to
CIS
2 LEDA1
O 6.27 to 6.93V DC CIS LED anode
3LEDCB1
O 1.47 to 4.43V DC CIS LED cathode(blue)
4LEDCG1
O 1.47 to 4.43V DC CIS LED cathode(green)
5 LEDCR1
O 2.97 to 5.43V DC CIS LED cathode(red)
6GND
- - Ground
73.3V4F
O 3.3 V DC 3.3 V DC power output to CIS
83.3V4F
O 3.3 V DC 3.3 V DC power output to CIS
9VREF
O 1.0 to 1.2V DC CIS reference voltage
10 MODE
O 0/3.3 V DC Resolution select signal
11 GND
- - Ground
12 CLK
O 0/3.3 V DC(pulse) DC(pulse) Clock signal
13 GND
- - Ground
14 GND
- - Ground
15 SP
O 0/3.3 V DC Sampling signal
16 GND
- - Ground
17 GND
- - Ground
18 Vout3
I Analog CIS Image output signal
19 GND
- - Ground
20 Vout2
I Analog CIS Image output signal
21 GND
- - Ground
22 Vout1
I Analog CIS Image output signal
23 GND
- - Ground
24 Vout0
I Analog CIS Image output signal
25 GND
- - Ground
26 LEDA2
O 6.27 to 6.93V DC CIS LED anode
27 LEDCB2
O 1.47 to 4.43V DC CIS LED cathode(blue)
28 LEDCG2
O 1.47 to 4.43V DC CIS LED cathode(green)
29 LEDCR2
O 2.97 to 5.43V DC CIS LED cathode(red)
30 GND
- - Ground
Connector Pin Signal I/O Voltage Description
