Front Panel Interface

PLM Series Operation Manual rev 1.1.9

Soft Reset

A Soft Reset will reset all settings and parameters to the original factory-dened default values, but retains

Frame Preset information and IP / Network conguration. A power cycle is not required to complete this

type of reset.

7.11.5.3 Breaker Emulation Limiter (PLM 20000Q ONLY)

MENU > FRAME > BREAKEMULIM

The Breaker Emulation Limiter (BEL) provides ampere selection (5-32 A) and breaker type selection

(CONSERVATIVE, FAST and SLOW). Select by pressing the adjacent button then use the rotary encoder to

change the parameter.

This option is only available for the PLM 20000Q.

7.11.5.4 Network

MENU > FRAME > NETWORK

Pressing the NETWORK button displays a further screen containing network conguration information.

All parameters are view-only on the front panel and are either not editable, or can only be adjusted via the

Lake Controller.

A summary at the top right of the screen conrms whether a valid connection is present for both Ethernet

ports, and whether the Lake Controller is online.

▸ IP Addr: Displays the Internet Protocol address for the selected unit and can only be changed via the

Lake Controller software. Please refer to the Lake Controller Operation Manual for further details.

▸ IP Mask: Displays the IP address subnet mask for the selected unit and can only be changed via the

Lake Controller software. Please refer to the Lake Controller Operation Manual for further details.

▸ MAC: Displays the unique Media Access Control Ethernet address for the processor. This value cannot

be changed.

▸ F.ID: Displays the Frame ID, a unique Lake product identier that cannot be changed.

7.11.5.5 Latency Match

To turn Latency Match on or off, select the parameter using the adjacent button then change the status

using the rotary encoder.

When Latency Match is ON the LM 26 adds delay to match the overall processing delay of legacy Lake

Contour Pro 26 and Mesa Quad EQ products. Please refer to the Lake Controller Operation Manual for

further information.
