Lab.gruppen PLM Series User Manual

Front Panel Interface
57
PLM Series Operation Manual rev 1.1.9
7.11.6 Front Panel Display Controls
MENU > FRAME > FRONT
Figure 7-17: Front Panel Display Controls Menu
Contrast
To adjust the front panel LCD contrast, select this option then use the rotary encoder to change the value.
Dimming
To adjust the front panel LCD brightness, select this option then use the rotary encoder to change the value.
Channel Order
To adjust the order in which both inputs and outputs are displayed on the front panel in all views, select this
option then use the rotary encoder to change the value between TOP-DOWN (default) and BOTTOM-UP.
7.11.7 Frame Preset Menu
MENU > FRAME PRST
Figure 7-18: Frame Preset Menu

Lab.gruppen PLM Series Specifications

General

DSP	Yes
Network	Ethernet
Connectors	XLR, SpeakON
Cooling	Forced air
Protection Features	Overheat, DC, short circuit
Control Software	Lake Controller
