31Expert(t) 2000
TM
Maintenance Manual
• If the truck is equipped with
the following type of tank,
turn the valve one-quarter
turn.
Figure 30. Air tank
• If the drain valve is
equipped with a steel cable
(see Figure 31. “Air tank
with steel cable on drain
valve”), the operator has to
pull the cable in order to
open the valve.
Figure 31. Air tank with steel cable
on drain valve
• When the air tanks are not
easily reachable, extension
hoses join them to ball
valves in order to perform
draining remotely
(optional).
Drain valve
