2. MACHINE INFORMATION
7
2-2. SPECIFICATIONS
ITEM MODEL
Sliding table dimension 3200x378mm
Cast Iron table 548x896mm
Extension table (rear) 952x896mm
Extension table (front) 830X320mm
Table size 1500x1726mm
Round rail Φ40mm
Main saw blade (Max.) 400mm
Main saw bore φ30mm
Max. cutting height at 90 (400mm) 130mm
Max. cutting height at 45 (400mm) 90mm
Main motor power (1ph) 5 HP (3.75 KW)
Main blade speed 3000/4000/5000rpm
Scoring saw blade φ 120mm
Scoring saw blade bore φ20mm
Scoring blade motor power 1 HP (0.75kw)
Scoring blade speed 8000 rpm
Cutting width 1300mm
Cutting width adjustment Manual
Main saw blade tilting adjustment
Manual(0
∘
~ 45
∘
)
Main saw height adjustment Manual
Scoring saw adjustment Manual
Saw guard
Simple (overhead guard as option)
Dust collection system (For overhead guard) 120/63mm (120/102mm)
Motorized rip fence (optional) Motorized
N.W./G.W./MEAS.: (Machine) 535/635 kgs (2110x1200x1110mm)
N.W./G.W./MEAS.: ( sliding table) 115/150kgs (3390x490x370mm)
N.W./G.W./MEAS.: (overhead guard) 28.5/32 kgs
Ctn QTY (with overhead guard) 7/17sets
Due to needs of continuous improvement, specification is subject to change without prior notice.
