4. OPERATION
28
III. USE OF SCORING BLADE
The scoring blade is used to avoid the chipping on the bottom pat of panels coated
with finishing material. Take Fig 4-2.3 as reference.
A. Single blade: with blade thickness equal to the saw blade one.
B. Double blade: If you fit proper shims between the two elements, you get the
same thickness of the saw blade or a larger thickness.
C. Conical scoring blade: For aligning with saw blade of different thickness or for
obtaining two chamfers on two panel edges.
If the edge which shall not be is only one, the scoring blade may have any shape and
dimension.
Figure 4-2.3
