3. INSTALLATION
11
3-2 Fitting the foot brake
1. Fit the foot brake to the right side of machine body, Remove the cover of the
control, loosen the screws on the foot brake to open it, remove the nut at the
back side of the brake attach to the machine aim the hole (only 2 holes as shown
below) Fasten the nut when attached the brake and finish adjust the position.
