5. MACHINE MAINTAINESS
40
5-2. PERIODICAL LUBRICATION
An accurate lubrication ensures the long life of usage as well as the best performance
of the machine.
Weekly lubricate with grease
Worms B (Fig. 5-2.1) and toothed sector A (Fig.
5-2.2) for height adjusting and tilting of the saw
blade
CAUTION
Disconnect the electrical
and pneumatic system
before maintenance
Figure 5-2.1
Ｂ
ＢＢ
Ｂ
Figure 5-2.2
A
