10
2 Safety
2.2 Associated Automatic Flame Guard
The unit is available with and without an integral flame guard. Sensor types FFS08 IR/UV,
FFS07 IR/UV can be connected to the integral flame guard. When used without integral flame
guard, any tested flame guard in accordance with DIN EN 298 and/or DIN EN 230 and approv-
al for continuous operation may be connected to terminal 53 like the following (document no.
in brackets):
• Compact flame detector F200K1 and F200K2 (DLT7620)
• Compact flame detector F300K (DLT7650)
• Flame scanner F152 (DLT7665), with flame sensors FFS07/FFS07 Ex (DLT7665) and
FFS08 (DLT7665)
WARNING!
If the ETAMATIC is used with an integral flame guard, terminal 53 must not be connected to
any other components.
WARNING!
Electrical connection to appliances not listed in these instructions: only after consultation with
the manufacturers or a qualified expert.
If a flame guard, which is not approved for continuous operation, is connected, the approval
of the system for continuous operation expires.
Liability for proper functioning of the unit passes to the owner or operator.
If the unit is incorrectly operated, serviced or repaired by unqualified personnel, or if operation
is inconsistent with the specified intended purpose, liability for the unit’s correct functioning in
each case passes to the owner or operator.)
WARNING!
The type approval lapses in the event of modifications to the unit. The unit's inputs and outputs
must only be wired according to the specifications in these instructions.
LAMTEC GmbH & Co KG will not be liable for damage or injury arising out of a failure to ob-
serve the instructions above. The warranty and liability provisions contained in LAMTEC
GmbH & Co KG’s terms and conditions for and Supply, shall not be extended by virtue of the
instructions above.
Where reference is made to legislation, government regulations and standards, these are
based on the legal system of the Federal Republic of Germany.
