Lamtec ETAMATIC User Manual

76
9 Appendix
9.4 Fault Codes
Fault
Code
No.
Restart according to Description
TRD EN676
000 0 0 No fault code available for this fault
001 0 3 Ignition flame does not appear.
H/Ü Check flame stability.
Check wiring.
Check ignition transformer and pilot burner.
Check flame sensor.
Check Parameter 788.
002 0 0 parasitic light failure
H/Ü Check wiring.
Check setting flame sensor.
Check Parameter 788.
003 0 3 Flame fault during ignition
H/Ü Check flame stability.
Check ignition transformer and pilot burner
Check flame sensor settings
004 1 1 Flame fault during operation
H/Ü Check flame stability
The switch off time for digital input "flame signal is <200ms!
For this reason, a flame fault can also have another cause, e.g.:
- The fuel solenoid valves close.(EMV, low voltage))
- "gas pressure < min" switch off time <1s
FMS with 660 R 0016 V4.3 with burner stationary
Check wiring between FMS and 660R0016 V4.3
Change 660 R 0016 V4.3 if wiring is correct.
005 0 3 Flame signal does not appear during 1st safety time
H/Ü Check flame stability.
Check wiring.
Check ignition transformer and pilot burner.
Check flame sensor.
Check Parameter 774, 775 and 788.
006 0 3 Flame signal goes out during stabilising time
H/Ü Check flame stability.
Check set pilot burner.
Check flame sensor.
007 0 3 The flame signal extinguishes during the first safety time
H/Ü Check flame stability.
Check set pilot burner.
Check flame sensor.
ETAMATIC: Check Jumper.
008 0 0 The flame signal extinguishes during the second safety time
H/Ü Check flame stability.
Check wiring.
Check flame sensor.
