143
9 Appendix
Fault term. 61 Contact for signalling a fault condition
max. 0,5 A*, cos = 0,8...1
Times Pre-purge time of 1 - 999 seconds
Safety time in operation: 1 sec.
1. safety time: Oil 4 sec.
1. safety time: Gas 3 sec.
2. safety time: Oil 4 sec. (when starting without pilot burner = safety time)
2. safety time: Gas 3 sec. (when starting without pilot burner = safety time)
Storage of the
setpoint values and
variable data:
In EEPROM points typically 20, normally 11 with linear interpolation
Number of Curve
sets
2 (p.ex. for dual-purpose burner)
Regular Operating
State Input
by internal control module
Number of program
cycles
unlimited
Interfaces – 1 serial interface on 25-pole Sub-D-connector, addressable via LAMTEC adapter only
(Dongle 663P0600)(RS 232)
– 1 interface on 9-pole Sub-D-connector
WARNING!
Using the interface without the adapter may damage the device.
You may use devices according to EN60950/VDE 0805 only.
1 LAMTEC SYSTEM BUS interface on 9-pole plug
Lenght: max. 500 m
BUS-connection via 9-pole Sub-D-connector
BUS card optional for the following systems:
– Interbus (Phoenix)
– CAN-Bus (CANopen)
– PROFIBUS DP
– MODBUS
