Valid values are in the range [1; 255].
Allow Guest VLAN if EAPOL Seen:
The switch remembers if an EAPOL frame has been received on the port for the life-time of the port. Once the switch
considers whether to enter the Guest VLAN, it will first check if this option is enabled or disabled. If disabled (unchecked;
default), the switch will only enter the Guest VLAN if an EAPOL frame has not been received on the port for the life-time
of the port. If enabled (checked), the switch will consider entering the Guest VLAN even if an EAPOL frame has been
received on the port for the life-time of the port.
The value can only be changed if the Guest VLAN option is globally enabled.
Port Configuration:
The table has one row for each port on the selected switch and a number of columns, which are:
Port:
The port number for which the configuration below applies.
Admin State:
If NAS is globally enabled, this selection controls the port's authentication mode. The following modes are available:
Force Authorized:
In this mode, the switch will send one EAPOL Success frame when the port link comes up, and any client on the port
will be allowed network access without authentication.
Force Unauthorized:
In this mode, the switch will send one EAPOL Failure frame when the port link comes up, and any client on the port will
be disallowed network access.
Port-based 802.1X:
In the 802.1X-world, the user is called the supplicant, the switch is the authenticator, and the RADIUS server is the
authentication server. The authenticator acts as the man-in-the-middle, forwarding requests and responses between the
supplicant and the authentication server. Frames sent between the supplicant and the switch are special 802.1X frames,
known as EAPOL (EAP Over LANs) frames. EAPOL frames encapsulate EAP PDUs (RFC3748). Frames sent between the
switch and the RADIUS server are RADIUS packets. RADIUS packets also encapsulate EAP PDUs together with other
attributes like the switch's IP address, name, and the supplicant's port number on the switch. EAP is very flexible, in that
it allows for different authentication methods, like MD5-Challenge, PEAP, and TLS. The important thing is that the
authenticator (the switch) doesn't need to know which authentication method the supplicant and the authentication
server are using, or how many information exchange frames are needed for a particular method. The switch simply
encapsulates the EAP part of the frame into the relevant type (EAPOL or RADIUS) and forwards it.
When authentication is complete, the RADIUS server sends a special packet containing a success or failure indication.
Besides forwarding this decision to the supplicant, the switch uses it to open up or block traffic on the switch port
connected to the supplicant
5
Suppose two backend servers are enabled and that the server timeout is configured to X seconds (using the AAA
configuration page), and suppose that the first server in the list is currently down (but not considered dead).
Now, if the supplicant retransmits EAPOL Start frames at a rate faster than X seconds, then it will never get
authenticated, because the switch will cancel on-going backend authentication server requests whenever it
receives a new EAPOL Start frame from the supplicant.
And since the server hasn't yet failed (because the X seconds haven't expired), the same server will be contacted
upon the next backend authentication server request from the switch. This scenario will loop forever. Therefore,
the server timeout should be smaller than the supplicant's EAPOL Start frame retransmission rate.
Single 802.1X:
174
LANCOM GS-2310P/GS-2326(P) User Manual
5 Security
