Lanner HCP-72i1 - System Specification

10
www.lannerinc.com
Chapter 1:
Introduction
Thank you for choosing HCP-72i1. HCP-72i1 is a
2U rackmount network security appliance built
with Lanner’s unique Hybrid Telecommunications
Computing Architecture (HybridTCA™).
HCP-72i1 integrates control, management and data
processing in one system and is positioned as an ideal
solution for datacenters and telecommunications
carriers. It comes with two x86 mainboards, each
supporting two Intel Xeon E5-2600 series “Ivy Bridge EP”
processors on LGA2011.
HCP-72i1 can be fitted, via the three (max.) swappable
I/O blades, with up to 36 1GbE network ports or 24
10GbE network ports in an array of SFP or copper
combinations. This particular appliance also comes with
8 quad-channel DDR3 modules and 2 removable SAS/
SATA HDD bays, future-proofing most of the expansion
needs.
SFeatures:
Intel Sandy/Ivy Bridge EP Xeon® Processor E5-2697 •
v2 CPUs, with Patsburge-B 602 PCH
2 x86 CPU Blades in the rear, each blade support •
Ivy-Bridge E5-2600 v2 Family up to 130W CPU
Dual Mainboard Communication is through NTB •
port up to 20 Gbs bi-way
Each Blade Support 16x R-DIMM•
3 network I/O Blades on the front•
IPMI Port for Remote Management•
Removable Fan Module•
NEBS Ready Design•
2 x 2.5” HDD Bay•
Hinge LCD Module for Easy Diagnostics and •
Configuration
System Specification
Form Factor 2U Rackmount
Platform
Processor
Options
Intel Sandy / Ivy Bridge EP (Intel®
Xeon® Processor E5-2697 v2 (30M
Cache, 2.70 GHz)
Dual 2011 pin LGA sockets
Chipset Intel Patsburg-B 602
BIOS
64Mb Flash Memory with AMI®
BIOS
System
Memory
Technology
16 x 240-pin DIMM Sockets per
board
Max. Capacity
Up to 32GB DDR3 1600 ECC Regis-
tered DIMM
Socket 16 x 240-pin DIMM Sockets
OS Support
Supports 32-bit/64-bit
operating systems
Storage HDD Bays 2 x SATA 2.5” HDD/SSD
Networking
Outputs (per
board)
Management
Port
1 x RJ-45 Intel 82574L Gigabit
supports 10BASE-T,100BASE-T, and
1000BASE-T
SYNC Port 1 x SFP+ port
LOM Port
1 x RJ-45 at 10/100/1000 base-T
speeds
Console Port 1 x RJ-45 port
Ethernet
Expansion
3 x LAN I/O blades for network
modules. Each I/O slot supports PCIe
x8 Gen 3.0
I/O Interface
(per board)
Reset Button
1 x reset button
Software reset by default
Console 1 x RJ45
USB
1 x USB 2.0
1 x USB 2.0 pin header
ESD 1 x ESD jack
SATA
1 x internal SATA II connector
1 x mini PCIe connector (serving as
mSATA)
LCM
128 x 64 Graph LCM with 4 key pad
Hinge LCM
1 LED for power,1 LED for Status
and 1 LED for HDD
Expansion (per
board)
PCIe
3 x PCIe Gen3.0x8 (to front side
module)
1 x PCIe Gen 3.0x8 (NTB)
1 x PCIe Gen2.0x4 (for front I/O)
1 x PCIe Gen2.0 (for Mgmt port)
PCI N/A
Power supply
AC redundant 1,200W hot-plug,
auto-switching 85/264V, 13A
DC redundant 1,010W hot-plug,
auto-switching, -36 to -76V, 30A
System Cooling
5 x system fans each layer
Supports smart fan feature
Environment
Operating
Temperature
0º to 50º C
Operating
Humidity
5% to 95%
Dimensions W 431 xH 88 x D 720(mm)
Certication RoHS
