Connectors and Jumpers List
The tables below list the jumper and connector label of each board.
Labels Function
FAN1~5 FAN connectors
J14 Front Panel Reset Button Setting
CONN2 Power-On Button Pin Header
J12 CPLD Flash Pin Header
MPCIE1 Mini PCIe Socket
USBA1 USB connector
JSDO23 Security Override
J13 LPC Port 80
SPIROM1 SPI Flash ROM Update Pin Header
J23 SATA Connector
J26 SATA Re-driver Value Flash Pin Header
J11 CMOS clear
VGA1 VGA connector
CONN3 Hot Swap LED Pin Header
CONN1 Hot Swap MRL (Manual Retention Latch) Pin Header
