OPERATOR INSTRUCTIONS
28
Turntable
1
Turntable Top
2
Urethane Ring
3
Drive Ring with Home Proximity Actuator
4
Bearing Support Ring
5
Center Bearing
6
Motor and Belt Tensioner (Motor not Shown)
1
2
3
4
5
6
