Lantech QL-400 - Film Roll Is Empty; Film Break Recovery

OPERATOR INSTRUCTIONS
68
6.9 Film Roll is Empty
1.
Push the E-stop
2.
Replace the film roll.
3.
Thread the film.
4.
Reset the E-stop.
5.
Push Reset.
6.
Push Film Assist.
7.
Pull the film and attach it to the load.
8.
Push Start.
If the button is pushed in the Film Break Recovery mode:
• Use the Manual Jog screen to move the FDS and the turntable to the home position.
6.10 Film Break Recovery
The FDS and the turntable stop. The fault screen for Film Break shows on the touch screen.
1. Push to go to the Manual Override screen.
2. Push Film Assist.
3. Pull the film and attach it to the load.
4. Push Resume.
