OPERATOR INSTRUCTIONS
36
6.5.1 Select a Ready-to-Wrap Profile
There are 10 pre-programmed Profiles already set in your machine
Put a load on the turntable and see if you can find your load in the Ready-to-Wrap Profile selection
If you can, select the Profile
If you cannot identify your load in the list, continue to 6.5.2 and Create a Profile
Pre-programmed Profiles:
Regular Light Light load, with no sharp edges, that fits the pallet
Applies Light Film Tension
Regular Heavy Heavy load, with no sharp edges, that fits the
pallet
Applies Light Film Tension
Irregular Light Light load that does not fit squarely on the pallet
Applies Light Film Tension
Irregular Heavy Heavy load that does not fit squarely on the
pallet
Applies Light Film Tension
Sharp Edges Load has sharp edges and is inboard
Applies Moderate Film Tension
Incomplete Top Layer Load has a few extra boxes on top
requires hand-roping
4 Revolutions at a slow turntable speed
Soft Top Soft or Light Top Layer
Applies reduced Film Tension at the top of the load
Pre-wrapped Double Load Stacked loads that are wrapped
Applies 3 layers of film to the middle of the stacked load
Short Normal Short load that does not require roping
Applies Light Film Tension
Short and Inboard Short Load that is inboard (Not compatible
with XT) and requires hand-roping
4 Revolutions at a slow turntable speed
