Lantech QL-400 User Manual

SPECIFICATIONS
9
Turntable
Turntable Diameter
1651 mm (65”)
Turntable Speed
15 rpm
Turntable Height
70 mm (2 ¾”)
Turntable Bearing Support
1219 mm (48”) Diameter
Turntable Drive
1 hp (.75 kW) 230/460 VAC 1800 rpm 3 Phase, 50/60 Hz
TEFC
Motor - 40:1 Speed Reducer
Film Delivery System (FDS)
FDS Lift Drive
1/2 hp (.37 kW) 230/460 VAC 1800 rpm TEFC
37:1 Speed Reducer
24 VDC Brake
Film Pre-stretch
Power Roller Stretch Plus with EZ Thread and Pallet
Grip®
FDS Drive
1/2 hp (.37 kW) 230/460 VAC 3 Phase, 1800 rpm TEFC
Film Pre-stretch Percentage
250%
Film
All Commercial Grade Films (50 - 150 Gauge)
Standard Film Capacity
254 mm (10”) Diameter
508 mm (20”) Width (Standard)
762 mm (30”) Width (Optional)
Film Tension
Electronically controlled with Reduced Film Tension at the
start of the wrap cycle
Auto Film Cut-off
Automatically cuts the film at the end of the wrap cycle
Electrical Requirements
Electrical Supply
Dedicated, Grounded Electrical Supply
Do not use on GFCI circuit
Power - US
120 Volts, 20 Amps
Power - EU
220 Volts, 16 Amps
Controls
Single Board Computer with Touch Screen Interface
Communications
IP Address
192.168.139.128
Network Mask
255.255.255.0
Gateway IP
192.168.139.2
DNS
192.168.139.2
Warranty
5 Years
