WaveSurfer DSO
WS-OM-E Rev B 23
Rapid Signal Processing
Processor: Intel Celeron 850 with MS WindowsXP Embedded platform
Internal Waveform Memory
Waveform: M1, M2, M3, M4 (Store full-length waveforms with 16 bits/data point.) Or save to any
number of files (limited only by data storage media).
Setup Storage
Front Panel and Instrument Status: Save to the internal hard drive or to a USB connected
peripheral device.
Auxiliary Output
Signal Types: Select from calibrator or control signals output from front panel.
Calibrator Signal: 1 kHz, 1 V square wave
Control Signals: trigger enabled, trigger out, or pass/fail
Auxiliary Input
Signal Types: Select External Trigger input on front panel. EXT: 100 mV/div; EXT/10: 1 V/div
Math Tools (standard)
Operators include sum, difference, product, ratio, and FFT (up to 25 kpts with power spectrum
output and rectangular, Von Hann, and Flattop windows). One math function may be defined at a
time.
Extended Math (MathSurfer option)
Adds chaining of two math functions, rescaling to different units, and the following additional math
functions:
absolute value
averaging (summed and continuous)
derivative
envelope
enhanced Resolution (to 11 bits)
floor
integral
invert
reciprocal
roof
square
square root
Measure Tools (standard)
Display any 6 parameters together with statistics, including their average, high, low, and standard
deviations. Measurements can be gated to focus on only a portion of the waveform.
