WaveSurfer DSO
WS-OM-E Rev B 91
5. Read the status information in line StatusDescription.
Statistics
By touching the Statistics On checkbox in the "Measure" dialog, you can display statistics for
standard vertical or horizontal parameters, or for custom parameters. The statistics that are
displayed are as follows:
value (last)
mean
min.
max.
sdev
num
The values displayed in the num row is the number of measurements computed. For any
parameter that computes on an entire waveform (like edge@level, mean, minimum, maximum,
etc.) the value displayed represents the number of sweeps.
