Operator's Manual
78 WS-OM-E Rev B
SAVE AND RECALL
Saving and Recalling Scope Settings
You can save or recall scope settings to or from hard disk, floppy disk, or LAN location.
To Save Scope Settings
1. In the menu bar, touch File; then touch Save Setup... in the drop-down menu. Or, press
the Save/Recall front panel button, then touch the "Save Setup" tab.
2. To Save To File, touch inside the Save Instrument Settings data entry field and use the
pop-up keyboard to enter the path to the destination folder. Or touch Browse to navigate
to the destination folder. Then touch
below the data entry field. To save to
folder Internal Setups on the scope's hard drive, touch inside a SetupX data entry field
and use the pop-up keyboard to enter a file name. Touch
alongside the data
entry field. The file is deposited in D:\Internal Setups, and the current date is displayed
above the field.
To Recall Scope Settings
1. In the menu bar, touch File; then touch Recall Setup... in the drop-down menu.
2. To Recall From File, touch inside the Recall panels from file data entry field and use
the pop-up keyboard to enter the path to the source folder. Or touch Browse to navigate
to the source folder. Then touch
. To recall settings from folder D:\ Internal
Setups on the scope's hard drive, touch
alongside the file you want to recall.
