Operator's Manual
24 WS-OM-E Rev B
amplitude
area
base
delay
duty cycle
fall 80-20%
fall time (90-10%)
frequency
maximum
mean
minimum
overshoot-
overshoot+
peak-to-peak
period
rise 20-80%
rise time (10-90%
rms
skew
std. deviation
top
width
Pass/Fail Testing
Test multiple parameters against selectable parameter limits at the same time. Pass or fail
conditions can initiate actions including: document to local or networked files, email the image of
the failure, save waveforms, or send a pulse out at the front panel auxiliary BNC output.
General
Auto Calibration: Ensures specified DC and timing accuracy is maintained for 1 year minimum.
Power Requirements: The instrument operates from a single-phase, 100 to 240 V
rms
(+/-10%)
AC power source at 50/60 Hz (+/-5%), or single-phase 100 to 120 V
rms
(+/-10%) AC power source
at 400 Hz (+/-5%).
Voltage Range: 90 to 132 V
rms
90 to 264 V
rms
Frequency Range: 380 to 420 Hz 47 to 63 Hz
Power Consumption: On State: up to 200 VA (4-channel models) or 170 VA (2-channel models)
depending on accessories installed (probes, external printer, PC port plug-ins, etc.)
Physical Dimensions (HWD): 260 mm x 340 mm x 152 mm (10.25 in. x 13.4 in. x 6.0 in.); height
measurement excludes foot pads
Net Weight: 6.8 kg (15 lbs.)
Warranty and Service
3-year warranty; calibration recommended yearly
Optional service programs include extended warranty, upgrades, and calibration services.
