LeCroy WAVESURFER User Manual

Operator's Manual
82 WS-OM-E Rev B
2. In the "Recall Waveform" dialog, touch the Recall From
or button.
A. If you selected Memory, touch inside the Source field and select a memory location:
M1 to M4.
B. If you selected File, touch inside the Destination field and select a memory location
in which to store the file.
Touch inside the Show only files field and select an area to limit the search to:
channels, math functions, or memory.
Touch inside the Recall files from directory data entry field and enter the path,
using the pop-up keyboard. Or touch the Browse button to navigate to the file.
Touch inside the Next file will be recalled from data entry field and enter the path,
using the pop-up keyboard. Or touch the Browse button to navigate to the file.
3. Touch
.
Disk Utilities
Use the Disk Utilities dialog to delete files or create folders.
To Delete a Single File
1. Touch File in the menu bar, then Disk Utilities... in the drop-down menu.
2. Touch the Delete button
in the "Disk Utilities" dialog.
3. Touch inside the Current folder data entry field and use the pop-up keyboard to enter
the path to the folder that contains the file you want to delete. Or touch the Browse
button and navigate to the folder.
4. Touch inside the File to be deleted data entry field and use the pop-up keyboard to enter
the name of the file. Or touch the Browse button and navigate to the file.
5. Once you have located the file, touch the Delete File button.
To Delete All Files in a Folder
1. Touch File in the menu bar, then Disk Utilities... in the drop-down menu.
2. Touch the Delete button
in the "Disk Utilities" dialog.

LeCroy WAVESURFER Specifications

General

Input Coupling	AC, DC, GND
Interface	USB, LAN, GPIB (optional)
Channels	4
Display	10.4" LCD
Vertical Resolution	8 bits
Input Impedance	1 MΩ || 50 Ω
Max Input Voltage	400 Vpk (1 MΩ)
Trigger Modes	Edge, Pattern
Bandwidth	200 MHz to 1 GHz
