LeCroy WAVESURFER User Manual

Operator's Manual
52 WS-OM-E Rev B
.
Max.
1.000 V
Default
0 mV
Min.
1.000 V
5. Select the holdoff by touching the Time or Events buttons , . Using the
pop-up numeric keypad, enter a value and specify the unit of time
, or use the
up/down buttons
to increase or decrease the time value in increments
of 200 ps. Or, touch one of the preset value buttons:

LeCroy WAVESURFER Specifications

General

Input Coupling	AC, DC, GND
Interface	USB, LAN, GPIB (optional)
Channels	4
Display	10.4" LCD
Vertical Resolution	8 bits
Input Impedance	1 MΩ || 50 Ω
Max Input Voltage	400 Vpk (1 MΩ)
Trigger Modes	Edge, Pattern
Bandwidth	200 MHz to 1 GHz
