6. Assembly
Recorded picture diagonal in mm for
1 inch 2/3 inch 1/2 inch 1/3 inch
camera camera camera camera
Without zoom magnification, for 1-chip cameras only:
C-mount adapter 1 x HC 16 11 8 6
C-mount adapter 0.63 x HC - 17.5 12.7 9.5
C-mount adapter 0.5 x HC - - 16 12
C-mount adapter 0.35 x HC - - - 17.1
With zoom magnification (vario TV adapter) for 1-3 chip cameras:
C-mount, 0.32-1.6 x HC - - 19
+)
-5 18-3.8
B-mount (ENG), 0.5-2.4 x HC (1/2-inch) - - 16-3.3 -
+)
from zoom factor 0.42 x only!
Without zoom magnification, for 1-3 chip cameras:
C-mount adapter 1 x - - 16 12
B-mount adapter 1 x - - 16 12
B-mount adapter 1.25 x - 17.5 - -
F-mount adapter 1 x - - 16 12
F-mount adapter 1.25 x - 17.5 - -
Plus (Essential Requirement): TV optics 0.5 x HC
6.8 Lambda Plate Compensator*
• Raise the condenser to it’s upper stop
position.
• Remove the DLF filter magazine from the base
if present.
• Attach the lambda plate compensator to the
base.
6.9 DIC Prisms
The condenser prisms have already been
mounted at the factory.
To adjust the condenser prisms during first use
→ p. 34.
To retrofit DIC prisms, see → p. 69.
6.10 Optional Accessories
Camera
A camera can be connected via an adapter.
• Attach the adapter to the top port of the tube
and fasten it tightly with the side clamping
screw.
• Screw on the camera.
Note:
The size of the camera chip and the mounting
system (B-mount, C-mount, etc.) must be
considered when choosing an adapter.
See table.
