30
6. Assembly
Fig. 31 Back of the Stand
1 Power supply connection
1
Tracing device
The tracing device L3/20 (fig. 30) allows an
optical overlay of large objects (next to the
microscope) on the microscope image. This
makes it easy to draw specimens by tracing
their outlines or superimposing scales.
6.11 Connection to the Power Supply
• After completing the assembly work, connect
the stand to the power supply using the power
cable supplied (fig. 31).
•When using the lamp housing or the
external power supply unit, connect them to
the power supply, too.
1
Fig. 30 Tracing device
1 Shutter
