Figure 113: Plate Alignment
11. Ensure the front edge of the end cap delete plate lines up with the edge of the end cap. Attach to
the end cap and press together to adhere the tape.
End cap notch delete plate line up
End cap notch delete plate in place
Figure 114: End Cap Alignment
12. Repeat the above steps for the other two endcaps.
13. Reassemble scanner.
