11.11 Cosmetic Mast Wrap
1. Retrieve the two rolls of cosmetic mast wrap (3000-32879-00).
2. Unroll the first wrap and remove the protective film from both sides, as shown in the following
figure.
Figure 58: Cosmetic Mast Wrap Protective Film Being Removed
3. Wipe down the now filmless wrap with electrostatic discharge (ESD) wipes (490-26003) included in
the hardware kit.
4. Fold the wrap around the mast so that its ends meet vertically along the back (outside) of the mast and
the holes line up as shown in the following figures.
Figure 59: Cosmetic Mast Wrap Installation
