ProVision 3 Installation Manual

8100-35521-00

Rev. A0

Leidos Security Detection & Automation, Inc. – Proprietary Page 106 of 119

36.0 Appendix C: OCP and Belt Barrier

37.0 Purpose

This procedure is to be followed when installing an OCP mounting kit and/or belt barrier on a

ProVision 3 or SafeView system.

38.0 Scope

Both manufacturing and field service can use this document to install the options as required.

39.0 Applicable Documents

Refer to assembly manual supplied with monitor support post.

40.0 Definitions

OCP - Operator Control Panel

PPH - Phillips PanHhead

FSHC - Flanged Socket Head Cap

ROW - Rest of World

TSA - Transportation Safety Administration

41.0 Requirements

CAUTION

Always disconnect power from the system prior to removing panels or any disassembly. Use the Lock

Out/Tag Out procedures (8400-10708-WI) when performing this instruction.
