ProVision 3 Installation Manual
8100-35521-00
Rev. A0
Leidos Security Detection & Automation, Inc. – Proprietary Page 103 of 119
© 2020 Leidos. All rights reserved
30.0 Appendix C: Label Kit
31.0 Purpose
The purpose of this appendix is to provide instructions to field personnel for placing labels on the power
entry panel after customer has defined whether power entry is to be from the bottom or top of the system.
Also explained is the labeling procedure when the customer decides to change the power entry scheme of
an installed system.
32.0 Scope
This procedure applies only to Provision 3 systems and to be used by customer service technicians or in
some cases factory assemblers.
33.0 Requirements
 Customer has defined whether power is to enter at the top or bottom of the system.
 Power entry panel has been installed.
 System in place and leveled.
33.1 Tools and/or Equipment
 Mini Level or any small level such as a torpedo level.
 1600-23775-00 KIT,LBL,PWR ENTRY PNL,ROW,PV2 or
 1600-25550-00 KIT, LABEL, PV2, TSA
Leidos P/N
Description
Qty.
Remarks
6000-21170-00
LBL, SYSTEM ID, PV2
1
Printed with the system
model number. and S/N.
510-26395
LBL, WARNING HIGH LEAKAGE
CURR
1
6000-21172-00
LBL, PROV. SYS P/N-Rev
1
Printed with the system.
P/N and revision.
510-26423
LBL, FCC CERT
1
510-26433
LBL, PATENT No. SPEC
1
6000-22199-00
LBL, 2" X 1", PART NUMBER
ONLY
1 ROW
0 TSA
6000-21320-00
LBL, MOTOR END COVER ONLY
1
510-21471
LABEL WARNING-MOVING
PARTS
1
34.0 Responsibilities
Anyone that needs to apply the system labels on the power entry panel.
