ProVision 3 Installation Manual

8100-35521-00

Rev. A1

Leidos Security Detection & Automation, Inc. – Proprietary Page 23 of 119

Figure 8: Installation Kit

3. Unscrew and remove the wood chock used to prevent the Genie Lifts from moving during transport.

4. Roll the Genie Lifts out of the installation kit crate.

5. Remove the straps securing ladders (with kits including ladders) to the Genie Lifts.

6. Set all items aside.
