Figure 108: Clean Area with Wipe

4. Determine which way the end cap delete plate [3000-25159-00] will be applied to the end cap.

5. If the back plate (3000-25159-01) has the double sided tape applied, skip to step 7.

6. Clean the backing plate [3000-25159-01] and the end cap notch delete plate (3000-25159-00)

with alcohol.
