5.4008.8573.0 B
2-8 Safety
Figure 5. Battery
KEY: 1. Battery - 2. Battery On/Off button
The on/off button (2) on the battery (1) can be used to switch off the power to the machine.
2.3.2 Safety Devices on the Charger
The software on the charger detects if the nose pad of the machine is under the charger. Only when the
nose pad is detected the magnetic field is activated to charge the battery.
The software keeps track up to which percentage the battery is charged. If the battery is fully charged to
80% of the maximum capacity, the magnetic field for charging is deactivated.
