5.4008.8573.0 B
6-6 Maintenance
1. Clean the following parts of the charger first with a plastic scraper, and then with a moist cloth or a
soft brush and water.
• Mushroom shaped knobs
• Charge pad
• Scraper
• Transparent plate
Figure 30. Charger parts
KEY: 1. Scraper - 2. Charge pad - 3. Mushroom shaped knobs - 4. Transparent plate
2. Make sure the charge pad and knobs can move to the left and right and to the back and front.
Close-up
1. Manually drive the machine under the charger.
2. Start the day planning to put the machine into operation.
6.6 Clean the Top Air Filter and the Level Sensor
Toxic gasses.
Risk of losing consciousness.
Only remove the air filter from the manure tank when the machine is
in a well ventilated area. Be aware of toxic gasses that may release
from the manure tank. Before removing the air filter, empty the tank
of the machine.
Preparation
1. Take the machine out of operation.
in novators in agriculture
