Table 3 Specifications Water Filling Station (cont'd.)
Water reservoir assembly
• Width: 680 mm (26.8 in).
• Height: 725 mm (28.5 in).
• Depth: 340 mm (13.4 in).
• Weight: 15 kg (33 lb); completely filled: 85 kg (187 lb).
Water Requirements.
• Min. water inlet pressure header tank: 1 bar (14.5 psi).
• Max. water inlet pressure header tank: 3 bar (43.5 psi).
• Min. required water flow for filling the header tank: 5 l/min (1.3 us
gal/min).
• Use potable water to prevent blockage of the nozzle or the water
pump.
Hygiene protection.
The header tank meets the standard ‘NEN-EN 1717:2000 en’ which
deals with the means to be used to prevent the pollution of potable
water inside premises and the general requirements of protection
devices to avoid pollution by backflow.
3.4 Dump Station
Table 4. Specifications Dump station
Dump station
Dump hole
dimensions
(recommended).
Inside the barn
• Width: 1200 mm (47 in).
• Length: 500 mm (20 in).
Large dump hole
(lagoon)
No recommendations.
Syphon For more information see the documentation of the
Lely Sphere, the syphon fits in a hole of:
• Width: 1200 mm (47 in).
• Length: 500 mm (20 in).
Dump hole is required
after a distance of:
• >160 m (525 ft) (on a closed floor).
Ventilation
requirements
The area around the dump pit must be well ventilated
especially when there is a combined dump pit and
charger.
