5.4008.8573.0 B
3-2 Specifications
Table 1 Specifications Mobile Barn Cleaner (cont'd.)
Noise emission in accordance
with EN-ISO 4871
Emission sound pressure level
(LpA).
~76 dB [A].
with a silencer (optional): <70 dB.
Requirements
• Ambient temperature: –20 °C to +50 °C (-4 to 122 °f)
• Humidity: 5 - 99 %, non condensing
• Maximum altitude: 2000 m (6561 ft)
• Operates inside the barn and drives occasionally outside for
dumping, this can be in all kinds of weather conditions.
• Operates in an environment with sufficient light for humans and
animals to see the device.
• Space needed for maintenance: approximately 2x2 m (6.5x6.5 ft)
3.2 Charging Station
Table 2. Specifications Charging Station
Charging station
Dimensions and weight.
• Width: 440 mm (17.3 in).
• Depth: 840 mm (33 in).
• Height: 780 mm (30.7 in).
• Weight: appr. 36 kg (79.3 lb).
Electrical properties battery
charger.
• Input voltage: 230 VAC (50 Hz) or 110 VAC (60 Hz).
• Nominal output voltage: 28.5 VDC.
• Max. charge current: 30 A.
• Max. power: 1kW.
Requirements
Inside a barn protected from direct rain and other water sources.
3.3 Water Filling Station
Table 3. Specifications Water Filling Station
Water Filling Station
Dimensions and weight. Water filling unit:
• Width: 260 mm (10.2 in).
• Height: 475 mm (18.7 in).
• Depth: 490 mm (19.3 in).
• Weight: 18 kg (40 lb).
in novators in agriculture
