5.4008.8573.0 B
5-2 Operating Instructions
Moving machine
Risk of injury. Before opening the top cover, take the machine out of operation!
Make sure the top cover is closed when you control the machine manually or when it is in
operation mode!
Open the Top Cover
1. Take the machine out of operation by pushing the PAUSE button (1).
• The PAUSE button lights up.
Figure 19. Open the cover
KEY: 1. Pause button - 2. Lever - 3. Latch - 4. Cover
2. Lift the lever (2) that is located under the top cover (4).
3. Lift the top cover a bit and push the latch (3) while holding the cover.
4. Lift the top cover and tilt it completely back until it is resting on the manure tank.
in novators in agriculture
