5.4008.8573.0 B
Maintenance 6-11
Toxic gasses.
Risk of losing consciousness.
Only remove the air filter from the manure tank when the machine is
in a well ventilated area. Be aware of toxic fumes that may release
from the manure tank. Before removing the air filter, release the
manure from the tank.
Preparation
1. Take the machine out of operation.
2. Manually drive the machine to the dump pit and make sure the machine is not connected to the
charger.
3. Block the cow traffic.
4. Switch off the machine.
Remove and Clean
1. Remove the bolt (1), washer (2) and the seal (3) of the top air filter.
Figure 34. Remove the top air filter
KEY: 1. Bolt - 2. Washer - 3. Ring - 4. Cover - 5. Air filter - 6. Air hole - 7. Seal - 8. Air tube - 9. Manure tank - 10. Bracket - 11. Nail
2. Remove the top air filter cover (4).
in novators in agriculture
