Operation
102
12.5.1.2 Extending the SE linkage symmetrically
- Press the key to select the function extend linkage symmetrically.
The extend linkage symmetrically menu now appears.
The linkage can be extended symmetrically as follows:
Boom 1
Booms 2 + 3
Boom 4
- Press the key to preselect boom 1.
- Press and hold the key, any information is then displayed.
To extend boom 1:
- Operate the tractor's corresponding control unit.
- Press the key or another function key to cancel the preselection.
- Press the key to preselect booms 2 and 3.
To extend booms 2 and 3:
- Operate the tractor's corresponding control unit.
- Press the key or another function key to cancel the preselection.
- Press the key to preselect boom 4.
- Press and hold the key, any information is then displayed.
To extend boom 4:
- Operate the tractor's corresponding control unit.
- Press the key or another function key to cancel the preselection.
